Outdated DKIM keys are easy to crack
Use a key that's 2,048 bits long
Quite a few of the world's most-visited web domains are using DKIM keys for their mail that are too short. DKIM keys are published in the DNS by the registrants or operators of internet domains. Other mail gateways can then use the keys to check the authenticity of inbound messages from those domains. Using DKIM to sign outbound mail helps senders to make sure that legitimate mail is accepted, while allowing spoofed messages, spam and malware to be kept at bay.
However, a proof-of-concept attack has now shown that a short DKIM key can be cracked in less than 4 days on a cheap, run-of-the-mill cloud-server. Once the key was cracked, valid signatures were attached to spoofed messages supposedly from the hacked domain. The messages were then accepted by receiving mail gateways running out-of-date or incomplete DKIM checks.
More than 1,700 weak keys
The reported DKIM hack began with an analysis of Tranco's list of the 1 million most-visited web domains. Software developer Andreas Wulf first checked whether the domains were using the mail security protocols SPF, DKIM and DMARC. His analysis revealed that, of the 476,617 DKIM records he found, no fewer than 1,726 had DKIM keys shorter than 1,024 bits. That's too short, according to RFC 8301, published in 2018. RSA-based DKIM keys should now be at least 1,024 bits, and preferably 2,048 bits.
Figure 1: Of the 476,617 DKIM records found, 1,726 had RSA-based keys shorter than the prescribed minimum of 1,024 bits. [Source: Andreas Wulf]
Finding out a domain's private key
Having discovered that so many domains were using short keys, Wulf decided to see how easy it was to actually crack a 512-bit DKIM key by prime factorisation: the mathematical method for decomposing RSA keys. What he found was that cracking the key was remarkably easy. Using an off-the-peg, open-source software package on a cheap, run-of-the-mill cloud server, the job took less than 4 days.
Having worked out what the DKIM key's prime factors were, it was possible to compute the private key itself – which is supposed to be known only to the domain's registrant or operator. And, once you have the key, you can immediately start attaching valid signatures to fake mail.
Spoofed e-mail messages
Wulf was therefore able to attach a valid DKIM signature to spoofed e-mail messages, then send them out via various major mail handlers. Although most of the handlers rejected the messages because of the short DKIM key, some gave them a DKIM validation pass.
Under the DMARC protocol, a message passes validation if it achieves either an SPF pass or a DKIM pass. Consequently, any message that subverts the DKIM security mechanism as described will also get through DMARC security.
What domain registrants/operators can do
It's important to recognise that Wulf's DKIM hack depends on 2 things. First, the domain sending the mail (the 'signing domain') must have a weak DKIM key. Second, the receiving mail gateway must be configured to give a validation pass even in cases where the DKIM key is shorter than 1,024 bits. That typically implies out-of-date configurations being in use at both the sending end and the receiving end.
The solution for a domain registrant/operator is therefore simple: replace your old DKIM key with a new one that's preferably 2,048 bits long. (RFC 8301 still permits 1,024-bit keys, but advises against them.) When replacing an old key, it's important to remember that the new public key needs to be published as a DKIM record in the signing domain's zone (by means of a mini-rollover).
If you use Postfix with Amavis, the easiest approach is to use this command:
amavisd -c /etc/amavisd/amavisd.conf showkeys
If you use Exim, you'll find the DKIM keys in the directory '/etc/exim/keys/'. The public key is retrieved using this command:
openssl rsa -in dkim_rsa.private -out /dev/stdout -pubout -outform PEM
What mail gateway operators can do
Mail gateway operators need to check their configurations to see what the minimum key length for a DKIM validation pass is. RFC 8301 says that it should be at least 1,024 bits.
For Postfix in combination with Amavis and OpenDKIM, the setting is in the file '/etc/opendkim.conf':
## Specifies the minimum number of key bits for acceptable keys and signatures. MinimumKeyBits 1024
In Exim, validation based on a minimum DKIM key length of 1,024 bits is enforced using the variable '$dkim_verify_min_keysizes'. The default length can be adjusted using the variable '$dkim_key_length'. A complete example of the latter configuration is provided in the Exim documentation.
DKIM2
Work has now started on the development of a new version of DKIM, known as DKIMbis. The main reasons for updating the protocol are to resolve the problems with forwarders and aliases, to stop replay attacks and to prevent backscatter. With those aims in mind, a mechanism is being developed for in-transit cryptographic recording of each hop in the delivery path, any changes made, and the next hop towards the destination. For details, see these preliminary drafts.
